Electric Pedestrian Pallet Truck 1.5 Ton Anton

Electric Pedestrian Pallet Truck 1.5 Ton Anton Specification

Driver Motor
0.75 kW

Traveling Speed
4.5 km/h

Lifting Speed
36 mm/s (laden), 52 mm/s (unladen)

Turning Radius
1465 mm

Brake
Electromagnetic Brake

Load Capacity
1.5 Ton

Application
Material Handling, Warehousing, Logistics

Condition
New

Power Source
Electric

Rated Capacity
1500 kg

Max. Lifting Height
200 mm

Max. Lifting Weight
1500 kg

Min. Lifting Height
85 mm

Fork Length
1150 mm

Fork Width
550 mm

Dimensions
1650 x 700 x 1200 mm

Service Weight
210 kg

Drive Wheel Size
210 x 70 mm

Noise Level
<70 dB(A)

Battery Voltage/Capacity
24V/65Ah

Operation Type
Pedestrian

Tyre Material
Polyurethane

Load Roller Size
80 x 70 mm

Controller
CURTIS Controller

Charger
24V/10A (Built-in)

Parking Brake
Automatic

About Electric Pedestrian Pallet Truck 1.5 Ton Anton

The AntOn by Jungheinrich Electric Pedestrian Pallet Truck PTL 1.5 is a 1.5 ton (1500 kg) electric walk-behind pallet mover designed for efficient, ergonomic material handling in warehouses, retail spaces, shop floors, and logistics operations. It combines electric travel and lift functionality with a compact, robust design, making pallet transport simple even in tight aisles and while loading or unloading trucks.

Enhanced Efficiency in Material Handling

With a rated capacity of 1.5 tons and a compact build, the Anton Electric Pedestrian Pallet Truck enables quick and reliable transportation of goods, minimizing manual labor and maximizing productivity in warehousing and logistics environments. Its ergonomic controls and automatic parking brake ensure safety and ease of use for operators.

Robust, Low-Maintenance Design

Built with polyurethane tyres and controlled by the trusted CURTIS system, the Anton Pallet Truck delivers excellent traction and long service life. The integrated 24V/10A charger simplifies battery management, and the low noise level (<70 dB(A)) allows for operation in noise-sensitive areas, enhancing workplace comfort.

FAQ's of Electric Pedestrian Pallet Truck 1.5 Ton Anton:

Q: How does the Anton Electric Pedestrian Pallet Truck improve warehouse operations?

A: The Anton Electric Pedestrian Pallet Truck enhances warehouse operations by allowing efficient, low-noise transportation of loads up to 1.5 tons. Its high lifting and traveling speeds, combined with simple pedestrian operation, streamline workflow, reduce physical strain, and optimize logistics processes.

Q: What is the battery capacity and charging process for this pallet truck?

A: The truck uses a 24V/65Ah battery and comes with a built-in 24V/10A charger. Charging is straightforward-simply connect to a power outlet after use. The ample battery capacity supports long working hours before recharging is needed.

Q: When is the Anton Pallet Truck most effective in use?

A: This pallet truck is most effective for moving heavy loads within warehouses, logistics centers, and industrial facilities that require rapid, repetitive material handling and where maneuvering in confined spaces is important.

Q: Where can this pallet truck be used?

A: The Anton Electric Pedestrian Pallet Truck is ideal for use in material handling, warehousing, and logistics environments, including distribution centers, export/import facilities, and manufacturing sites.

Q: What safety features are included in the Anton Electric Pedestrian Pallet Truck?

A: Safety is ensured through features such as the automatic parking brake and electromagnetic service brake. The truck is equipped with polyurethane tyres for stable traction and a CURTIS controller for precise maneuverability, minimizing risk during operation.

Q: What are the benefits of using the built-in charger?

A: The integrated 24V/10A charger eliminates the need for external charging equipment, streamlining battery maintenance. This feature enables operators to conveniently recharge the machine within the facility, reducing downtime and supporting uninterrupted workflow.
